The ARCAM A25 is the best sounding, and most feature rich of our Radia Integrated amplifiers. The visual luxurious highlights hint towards the more luxurious musical experience that it offers.

This is achieved with a 5th generation Class G amplifier design. You can expect the best sound quality and dynamics from what has always been a better sounding, and more efficient Class of amplifier. New components and materials have been painstakingly analysed and reviewed to ensure uncompromising sound performance.

The rich feature set includes a USB-C input for your laptop, be it PC, MAC or Raspberry Pie! This augments a Bluetooth solution that includes Qualcomm AptX Adaptive technology with 24-bit HD audio to ensure the best sound quality no matter what you are playing. It can also connect to Bluetooth headphones so your listening experience can continue sensitively after dark.

Like any ARCAM integrated amplifier, we pay particular attention to the built in phono stage to ensure your records sound as lush and engaging as possible.

Key Features

ARCAM Class G amplification - for ultra-low distortion

100W per channel (8Ω) - powers loudspeakers effortlessly.

Bluetooth with aptX™ Adaptive Technology - for the best sound with the most convenience

Specially selected components and materials - to deliver on sound quality

Wired or Wireless Headphones - connect your headphones for quiet listening with, or without wires

All new Radia design - Purposeful yet playful

MM phono stage - ready for Turntables

Hi-Res Digital Audio Inputs - with the addition of USB-C for ultra Hi-Res audio

Plastic Free Packaging - for easy disposal of natural materials

Specifications

Continuous power output (0.5% THD), per channel

2 channels driven, 20Hz - 20kHz, 8Ω 100W

2 channels driven, 1kHz, 4Ω 165W

Harmonic distortion, 80% power, 8Ω at 1kHz 0.002%

Analogue Inputs

Number of inputs 3 (RCA pairs)

Signal/noise ratio (A-wtd, ref. 50W, 1V input) 106dB

Frequency response 20Hz—20kHz ± 0.2dB

Phono (MM) Input

Input impedance 47kΩ + 100pF

Frequency response (ref. RIAA curve) 20Hz—20kHz ± 1dB

Digital Inputs

Supported Sample Rates (kHz)

USB-C 384, 352.8, 192, 176.4, 96, 88.2, 48, 44.1

Coaxial (RCA) 192, 176.4, 96, 88.2, 48, 44.1

Optical (Toslink) 192, 176.4, 96, 88.2, 48, 44.1

Supported DSD USB-C only 512, 256, 128, 64

Bit depths (bit) 32, 24, 16

Frequency response (fi lter 1) 20Hz—20kHz ± 0.2dB

Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) 110dB

Headphone Output

Maximum output level (RMS) into 32Ω/300Ω 2.5V/5V

Load range 16Ω - 2kΩ

General

Mains voltage 100V or 110–120V or 220–240V, 50–60Hz

Power consumption (maximum) 500W

Power consumption (standby) <0.5W

Dimensions W x D (including speaker terminals) x H (including feet) 431 x 344 x 83mm

Weight (net) 9kg

Weight (packed) 12kg

Supplied accessories

Mains lead(s)

Remote control with 2 x AAA batteries

Quick Start Guide

Important Safety Instructions
